Frigidaire FRA144HT2 User Manual

READ BEFORE INSTALLING UNITFor Through-the-Wall Air Conditioners1Installation InstructionsNOTE:DO NOT USE ANY SCREWS OTHER THAN THOSE SPECIFIED HERENo

Installation Instructions#7 WhirlpoolWall Sleeve Brands:1. Remove existing rear grille as shown on Page 3 of this manual and replace with provided lou

Installation Instructions#8 White Westinghouse/Frigidaire/Carrier 52F SeriesWall Sleeve Brands:1. Remove existing rear grille as shown on Page 3 of th

Installation Instructions#9 White Westinghouse or FrigidaireWall Sleeve Brands:1. Remove existing rear grille as shown on Page 3 of this manual and re

13Installation InstructionsDirect Unit MountingThe previous directions are the preferable way to mount the new rear grill. The unit’s performance is s

Installation InstructionsFINISHING INSTALLATION:142. Assemble the trim frame by inserting top and bottom pieces into side pieces and snapping in

2Installation InstructionsHow to Install1. Identify the wall-sleeve brand for your installation, from the chart below.BrandWall Sleeve DimensionsWidt

3Installation Instructions1. Remove the existing grille.2. Place the grille included with the new air conditioner towards the rear of the sleeve.3.

4Installation Instructions#1 EmersonWall Sleeve Brands:1. Remove existing NOTE: You may need to drill holes in flange of existing sleeve to matchnew r

Installation Instructions#2 FeddersWall Sleeve Brands:1. Remove existing rear grille as shown on Page 3 of this manual and replace with provided louve

Installation Instructions#3 Fedders or FriedrichWall Sleeve Brands:1. Remove existing rear grille as shown on Page 3 of this manual and replace with p

Installation Instructions#4 General Electric/HotpointWall Sleeve Brands:1. Remove existing rear grille as shown on Page 3 of this manual and replace w

Installation Instructions#5 Sears or Carrier 51S SeriesWall Sleeve Brands:1. Remove existing rear grille as shown on Page 3 of this manual and replace

Installation Instructions#6 WhirlpoolWall Sleeve Brands:1. Remove existing rear grille as shown on Page 3 of this manual and replace with provided lou
